Reiser Repak RE20 Thermoformer

The RE20 is a horizontal form, fill and seal machine. It is extremely flexible in the production of different packaging shapes and has superior packaging options. Specifications: 5,000 mm frame length Horizontal Form/Fill/Seal Vacuum Packaging machine Substantial mainframe constructed from 100% stainless steel Nominal web width; 420mm (16.53″) Maximum depth of draw: 120mm (4.72″) Omron PLC including 200mm (8″) user friendly Touch Screen with full operator interface and self diagnostic system, safety system, and history retrieval Omron AC Frequency Controlled Drive System Stainless steel electrical/pneumatic cabinet with hygienic sloped top Top and bottom 3″ film mandrels with integrated drag system Stainless steel product discharge chute Safety guarding with electronic interlock Independent, pneumatic hoisting stations – 150mm seal die opening Tool kit with standard spares assortment Master Die set 420mm x 220mm index Includes total seal plate Compressed air forming Side pin evacuation and gas flush Die Divider set 3.1 for use in Master die 220mm to package “bread products” Pocket dimensions: 125mm x 202mm (4.9′ x 7.9″) Package dimensions: 140mm x 220mm (5.5″ x 8.6″) Packs per index: 3 (3 tracks, 1 row) Index: 220mm (8.6″) Easy open peel corner Gas flush system integrated in base machine, includes pressure transducer and level sensor Cross cut assembly, zigzag cut with pneumatic hoisting Longitudinal, rotary knife cutting system including cartridge for safe removal of assembly with AC Motor Drive Knife assembly with package support for 3 lane Film Trim removal – Vacuum Trim Canister includes suction blocks, hose, and stainless steel clad vacuum canister Busch R5 Series Vacuum Pump internally mounted – RA0165, 117CFM, 7.5 HP motor Clear-Vu Vacuum filter Manual available 1977 / B1501ABBSH C4 condition: Good
